5.00-10", 4 Ply 4 on 4" PCD Wheel Assembly
Part No
WL105
Product Features:
○ Tyre Width: 5"○ Rim Diameter: 10"
○ Stud Circle Diameter: 4"
○ Stud Hole Diameter: 11mm
○ Speed Rating: 140kph max
○ Max Load: 355 kgs. per wheel @ 40 psi
15 available in stock
£68.40
£57.00
5.00-10 4 Ply 4 on 4" PCD Wheel Assembly
5.00-5.20 x 10", 4 ply, high speed tubeless tyre with 4 studs on 4" PCD. Entire wheel assembly, ideal for both caravans and trailers. Easy to fit to compatible trailers and caravans with 4 stud fixing. The max loading capacity of 355 kg per wheel at 40 psi is due to strong 4 ply tyre which gives flexibly loading options and gives you plenty of confidence when towing with heavy loads.
Style of rim may vary.
| Rim Diameter | 10" |
|---|---|
| Tyre Diameter | 535mm |
| PCD (Stud Circle Diameter) | 4" |
| J (Rim Width) | 3.5J |
| ET (Centre Offset) | 0mm |
| Centre boss diameter | 65mm with a cut out for grease nipple |
| Stud Hole Diameter | 11mm |
| No. of studs | 4 |
| Tyre Width | 5" |
| No. of Ply | 4 ply |
| Load Index | 72 |
| Speed Rating | N (140 KP/H max.) |
| Max load Single Axle (twin) | 355 kgs. per wheel @ 40 psi |
| Type | Crossply |
